KEC70 Series UHF/RF Power Ceramic CapacitorsHome > Products > High Q Ceramic Capacitors

Features

• Capacitance Range 0.1 pF to 120000 pF
• High Q
• High RF Power
• Low ESR/ESL
• Low Noise
• High RF Current/Voltage
• Ultra-Stable Performance

KEC70 Series UHF Datasheet

  • Applications
  • Main Specifications
Applications Field
• High RF Power Amplifier
• High Power Filter Network
• Antenna Demodulation etc
Series Name Size Footprint in. (mm) Cap. Value Range (pF) Working Voltage
(WVDC) Max.
TCC(ppm/°C)
(-55°C to +125°C)
PDF
KEC70F Series .614x.433 (15.6x11.0) 1.0 to 6800 8000 0±30
KEC70G Series .760x.760 (19.30x19.30) 1.0 to 20000 8000 0±30
KEC70L Series 1.30x1.30 (33.40x33.40) 200 to 120000 10K 0±30
